Mini Lathe Machine

Name: Mini Lathe Machine
Brand: UMA ENTERPRISE
Price: 110000 INR
Availability: InStock

110000 INR/Piece

Get a Price/Quote

Product Details:

Product Type Mini Lathe Machine
Material Cast Iron and Mild Steel
Cutting Thickness Up to 40 mm
Cutting Speed 50-2500 RPM
CNC Or Not Not CNC
Automatic Grade Semi-Automatic
Control System Manual
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mini Lathe Machine Price And Quantity

Price 110000 INR/Piece
Minimum Order Quantity 1 Piece

Mini Lathe Machine Product Specifications

Max. Swing Diameter 180 mm
Automatic Grade Semi-Automatic
Cutting Speed 50-2500 RPM
Product Type Mini Lathe Machine
Capacity Small Batch / Hobby Use
Material Cast Iron and Mild Steel
Dimension (L*W*H) 700 x 300 x 270 mm
Voltage 220V / 50Hz
CNC Or Not Not CNC
Control System Manual
Feature Precision, Compact Design, Low Noise
Color Blue & Silver
Cutting Thickness Up to 40 mm
Weight (kg) 45 kg

Mini Lathe Machine Trade Information

Supply Ability 20 Piece Per Month
Delivery Time 4-5 Days
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India

Product Description

diy mini lathe machine

Features:

Sturdy construction
Perfect finish
Longer service life
Noise-free operations

All Geared Lathe Machine :

Technical Specification in mm

Perticular	250
Description
Height of Centre(mm)	250
Swing Over Bed (mm)	490
Swing Over Cross Slide (mm)	290
Distance Between Center (mm)	965mm
Max. Swing in Gap (mm)	770
BED
Bed Type	2 V & 2 Flat
Bed Width (mm)	325
Length of Gap in Front of Face Plate (mm)	240
HEAD STOCK
Number of Feeds	18
Spindel Speed Range : R.P.M.	32 TO 1650
Spindle Bore ( mm)	55
Spindle Taper Number	MT - 4
FEEDS AND THREADS
Number of Feeds	76
Range of longitudinal Feeds (mm/Rev)	0.026 to 0.936
Range of Cross Feeds (mm/rev)	0.016 to 0.62
Number of Threads	106
Range of Metric Threads/No.	0.2 to 7 mm (33)
Range of Inch Threads,No.	72 to 4 TPI (36)
Range of Module Threads/No.	0.3 to 3 Module (16)
Range of D.P. Threads/No.	44 to 8 D.P. (21)
Leed Screw Dia (mm)	38.1
Leed Screw Pitch (mm)	6 mm
SADDLE
Cross Slide Dimension (mm)	460 x 205
Cross Slide Travel (mm)	200
Compound Slide Traverse (mm)	150
TAIL STOCK
Spindle Dia (mm)	63.5
Spindle Taper Number	MT-4
Spindle Travel	175
Lateral Move to Tail Stock (mm)	5
MOTOR
Main MKotor (Kw.)	3

STANDARD ACCESSORIES

Four Position Tool Post, Toolpost Spanners, Center Adopter, 2 Nos. MT-3 Dead Centers, Electric Motor with Electrical Controls, Thread Dial Indicator, Camlock operating Handle, Chip Tray.

EXTRA ACCESSORIES

Collet attachment
Machine Lamp
Quick change Tool Post
Collet ( 1 mm to 25 mm ) each collet cost
Chuck Flange 8"
Coolant Pump & Fitting
Collet ( 4 mm to 40 mm ) each collet cost
Chuck Flange 10"
Carrier Plate
Taper Turning Attachment
Face plate ( 350 mm Dia )
Extra Center Height 2"
Rear Tool Post
Follow Rest
Digital Read out System (DRO)
Mechanical Brake
Steady Rest

Note :

All The above specifications are approximate and subject to change without prior notice as improvements are made from time to time.
The Description " standard accessories / features " confirms to its list not the photo of models shown in the catalog.

Heavy Duty Lathe Machine :

Technical Specification in mm

Parts	Specification	Heavy-1	Heavy-2	Heavy-3	Heavy-4	Heavy-5
Bed	Length of Bed Width of Bed Lenght of Gap in Front of Face Plate	5 6" (1708) 12.75" (323) 7" (178)	7 (2135) 12.75"(323) 7" (178)	9 (2745) 12.75"(323) 7" (178)	10 (3050) 12.75"(323) 7" (178)	12 (3650) 12.75" (323) 7" (178)
Capacity	Height of Centre Swing over Bed Admit between center Movement of cross slide Movement of comp. slide	10" (254) 19" (480mm) 20" (508) 7II (190mm) 6" (152mm)	10" (254) 19"(480mm) 38 " (965) 7II (190mm) 6" (152mm)	10" (254) 19" (480mm) 62 " (1575) 7II (190mm) 6" (152mm)	10" (254) 19" (480mm) 74 " (1880) 7II (190mm) 6" (152mm)	10" (254) 19"(480mm) 98 " (2490) 7II (190mm) 6" (152mm)
Main Spindle	Spindle Nose Spindle Bore Tapper Bore	76 x 6 TPI 2.1/8 (54) MT - 4	76 x 6 TPI 2.1/8 (54) MT - 4	76 x 6 TPI 2.1/8 (54) MT - 4	76 x 6 TPI 2.1/8 (54) MT - 4	76 x 6 TPI 2.1/8 (54) MT - 4
Tail Stock Spindle	Diameter Morse tapper Travel	2.1/2" (63.5) MT - 4 7" (178mm)	2.1/2" (63.5) MT - 4 7" (178mm)	2.1/2" (63.5) MT - 4 7" (178mm)	2.1/2" (63.5) MT - 4 7" (178mm)	2.1/2" (63.5) MT - 4 7" (178mm)
Speed	No. of speed RPM Low & High	8 25 to 450	8 25 to 450	8 25 to 450	8 25 to 450	8 25 to 450
Threads	Metric thread Inch thread Lead screw	1 to 6 2 to 24 1II" (38mm)	1 to 6 2 to 24 1II" (38mm)	1 to 6 2 to 24 1II" (38mm)	1 to 6 2 to 24 1II" (38mm)	1 to 6 2 to 24 1II" (38mm)
Electric	Motor Power	3 H.P III	3 H.P III	3 H.P III	3 H.P III	3 H.P III
Drive	Counter to spindle Counter to motor	C 72 x 2 no. B 72 x 2 no.	C 72 x 2 no. B 72 x 2 no.	C 72x 2 no. B 72 x 2 no.	C 72x 2 no. B 72 x 2 no.	C 72x 2 no. B 72 x 2 no.
General	space (L x W x H)	81 x 45 x 50	99 x 45 x 50	122 x 45x50	134 x 45x 50	158 x 45 x 50

Technical Specification in mm

Parts	Specification	Medium 4 6"	Medium 5 3"	Medium 6
Bed	Length of Bed Width of Bed Length of Gap Length of Gap in Front of Face Plate	4 6" (1370mm) 11 " (280mm) 5" (127mm) 5" (127mm)	5 3 "(1600mm) 11 " (280mm) 5" (127mm) 5" (127mm)	6 (1830mm) 11 " (280mm) 5" (127mm) 5" (127mm)
Capacity	Height of Centre Admit between center Movement of cross slide Movement of comp. slide	8II (215mm) 20" (508mm) 6.75 (170mm) 5 " (127mm)	8II (215mm) 29" (740mm) 6.75 (170mm) 5 " (127mm)	8II (215mm) 38 " (965mm) 6.75 (170mm) 5 " (127mm)
Main Spindle	Spindle Nose Spindle Bore Tapper Bore	75mm x 6 TPI 2 1/8 " (55mm) MT - 4	75mm x 6 TPI 2 1/8 " (55mm) MT - 4	75mm x 6 TPI 2 1/8 " (55mm) MT - 4
Tail Stock Spindle	Diameter Morse tapper Travel	2" (50.8mm) MT - 4 6 (152mm)	2" (50.8mm) MT - 4 6 (152mm)	2" (50.8mm) MT - 4 6 (152mm)
Speed	No. of speed RPM Low & High	6 45 to 450	6 45 to 450	6 45 to 450
Threads	Metric thread Inch thread Lead screw	M 1 to 6 2 to 24 1I" (31.75mm)	M 1 to 6 2 to 24 1I" (31.75mm)	M 1 to 6 2 to 24 1I" (31.75mm)
Electric	Motor Power	2 H.P III	2 H.P III	2 H.P III
Drive	Counter to spindle Counter to motor	B - 48 x 2 no. B - 57 x 2 no.	B - 48 x 2 no. B - 57 x 2 no.	B - 48 x 2 no. B - 57 x 2 no.
General	Floor space (L x W x H)	65" x 39" x 55"	76" x 39" x 58"	84" x 39" x 55"

STANDARD ACCESSORIES

Chuck Plate, Face Plate, Change Gear Set, Steady Rest, Tool Post Key, Dead Centers, Center Adaptor, Motor Pully.

Note:Any Altertoin in respect of ourstd. specifiction will be welcomed at extra cost.

As improvements are constantly made in our machine the above specification, dimension and weight are subject to change without notice & are not binding on us.

Meduim Duty Lathe Machine :

STANDARD ACCESSORIES

Chuck Plate, Change Gear Set, Tool Post Key, Dead Centers, Center Adaptor, Motor Pully.

Note :

Any Altertoin in respect of ourstd. specifiction will be welcomed at extra cost.

As improvements are constantly made in our machine the above specification, dimension and weight are subject to change without notice & are not binding on us.

Light Duty Lathe Machine :

Technical Specification in mm

Parts	Specification	Light 4II
Bed	Length of Bed Width of Bed Length of Gap	4II (1370mm) 9II" (242mm) 4" (100mm)
Capacity	Height of Centre Swing over Bed Admit between center Movement of cross slide Movement of comp. slide	6II" (165mm) 12II" (320mm) 26" (661mm) 5" (127mm) 3" (75mm)
Main Spindle	Spindle Nose Spindle Bore Tapper Bore	60mm x 8 TPI 1II (40mm) MT - 3
Tail Stock Spindle	Diameter Morse tapper Travel	1 5/8" (40mm) MT - 3 4 (100mm)
Speed	No. of speed RPM Low & High	8 40 to 950
Threads	Metric thread Inch thread Lead screw	M 1 to 6 2 to 24 1" (25.4mm)
Electric	Motor Power	1 H.P III
Drive	Counter to spindle Counter to motor	B -42 B -52
General	Floor space (L x W x H)	65" x 28" x 55"

STANDARD ACCESSORIES

Chuck Plate, Change Gear Set, Tool Post Key, Dead Centers, Center Adaptor, Motor Pully.

Note :

Any Altertoin in respect of ourstd. specifiction will be welcomed at extra cost. As improvements are constantly made in our machine the above specification, dimension and weight are subject to change without notice & are not binding on us.

Precision and Versatility

The Mini Lathe Machine allows users to perform metal turning, drilling, and thread cutting with remarkable accuracy. Its variable speed capacity between 50-2500 RPM caters to different material requirements, making it suitable for both hobbyists and small-scale professional workshops. The inclusion of a tailstock quill and adjustable chuck ensures versatility in project execution.

Robust Yet Compact Design

Built from a combination of cast iron and mild steel, the lathe machine offers reliability without excessive weight. At just 45 kg, its manageable for most workspaces and can be relocated as needed. The machined and painted surface not only enhances the appearance but also improves durability against wear and tear.

Ease of Use and Maintenance

This semi-automatic lathe utilizes manual grease or oil lubrication, making routine maintenance straightforward. A comprehensive user manual and a set of standard accessories are included for a hassle-free initial setup and ongoing use. The noise level remains low, adding to user comfort during prolonged sessions.

FAQs of Mini Lathe Machine:

Q: How do I operate the Mini Lathe Machine for metal turning and drilling?

A: To operate the Mini Lathe Machine, securely mount your workpiece using the 100 mm chuck, select the appropriate speed via the variable control (50-2500 RPM), and use the handwheels to position the cutting tool. For drilling, center the workpiece and use the tailstock quill with 40 mm travel. The user manual provides comprehensive instructions for setup, operation, and safety precautions.

Q: What materials are compatible with this lathe and what is the maximum cutting thickness?

A: The machine is designed for use with metals, particularly suitable for projects using mild steel or cast iron. The lathe can accommodate pieces up to 40 mm in thickness and a maximum swing diameter of 180 mm, making it versatile for various small-scale applications such as hobby projects or repair work.

Q: When should I apply lubrication, and which type is recommended?

A: Regular manual lubrication using grease or oil is crucial for smooth and efficient operation. It is recommended to apply lubrication before each extended use session and after cleaning the machine. Refer to the maintenance section in the user manual for guidance on lubrication points and suitable products.

Q: Where can I install the Mini Lathe Machine for optimal performance?

A: This lathe is best installed on a stable, level workbench in a well-ventilated, dry area. Its compact dimensions (700 x 300 x 270 mm) and low weight (45 kg) allow for flexible placement, making it suitable for home workshops, educational laboratories, and small industry settings.

Q: What is the process for changing speeds and gears on this variable-speed lathe?

A: The lathe features variable speed control, which allows you to adjust the spindle speed from 50 to 2500 RPM using the built-in control mechanism. This enables quick adaptation to different materials and tasks without needing to manually change physical gears.

Q: How does the Mini Lathe Machine benefit small batch or hobby users?

A: The Mini Lathe Machines precision, compact design, and ease of use make it perfect for small batch production and hobby applications. Users benefit from low noise levels, straightforward manual controls, and reliable performance, enabling accurate and consistent results in metalworking projects.

Q: What accessories are included, and how do they contribute to overall usage?

A: This lathe package includes the machine itself, standard accessories necessary for typical operations, and a user manual. The accessories support immediate use upon delivery and simplify routine tasks, maintenance, and adjustments, ensuring a smooth user experience.
